A Flexible Product Range from Compact Ice Makers to High-Capacity Ice-Freezing Cabinets
As demand for cold drinks, food preservation and reliable ice supply continues to grow, solar-powered ice-making equipment is becoming increasingly useful in locations where conventional electricity is expensive, unstable or unavailable.
Our latest solar ice-making product range combines compact automatic ice makers with dedicated freezing and ice-storage cabinets. With support for DC12V, DC24V and 220V power options, these products can be integrated into properly configured solar-energy systems while also adapting to conventional electricity when required.
The current range includes the compact IM-10, the higher-output IM-30B, the BD-88 freezing cabinet, and the BD-198 series, available in BD-198-7, BD-198-10 and BD-198-11 configurations.
Together, these models provide practical options for homes, cafés, beverage shops, farms, fishing communities, outdoor businesses, rural stores and renewable-energy projects.
Why Solar Ice Making Is Becoming More Important
Ice is essential in many everyday and commercial activities. It is used for:
Cold beverages
Food and seafood preservation
Restaurants and cafés
Outdoor retail
Farms and fisheries
Hotels and small shops
Rural and remote businesses
Temporary events and mobile operations
In areas with strong sunlight but limited electrical infrastructure, solar-powered equipment can provide a more flexible way to produce and store ice.
A typical solar ice-making system may include:
Solar Panels → Charge Controller → Battery Storage → Ice Maker or Freezing Cabinet
The exact solar-panel and battery configuration should be selected according to the model, daily operating hours, local climate and required ice output.
IM-10 Compact Solar Ice Maker
Small Size for Daily and Mobile Ice Production
The IM-10 is a compact automatic ice maker designed for homes, small cafés, beverage stalls, offices, camping facilities and mobile applications.
Despite its small dimensions, it can produce up to 10 kg of ice in 24 hours under suitable operating conditions.
Main features
Daily ice output: 10 kg/24H
Water tank: 1.3L
Power consumption: 60W
Power options: 12V/24V/220V
Production cycle: 8, 10 or 12 minutes
Ice sizes: Small, medium or large
Ice quantity per cycle: 9 pieces
Ice storage: 0.6 kg
Working temperature: 10–30°C
Refrigerant: R134a
Product size: 226 × 295 × 293 mm
Its compact structure makes it easy to place on countertops, small workstations or mobile vending equipment. It is a practical choice for users who need moderate daily ice production without installing a large commercial machine.
IM-30B Commercial Solar Ice Maker
Higher Output for Shops, Restaurants and Small Businesses
The IM-30B is designed for users who require greater daily ice production and larger internal storage.
It can produce up to 30 kg of ice every 24 hours, making it suitable for restaurants, drink shops, grocery stores, hotels, food-service businesses and outdoor commercial operations.
Main features
Daily ice output: 30 kg/24H
Water tank: 3.0L
Power consumption: 150W
Power options: 12V/24V/220V
Production cycle: 15 minutes
Ice size: 23 × 23 × 23 mm
Ice weight: Approximately 9 g per piece
Output per cycle: 32 pieces
Ice storage: 11.5 kg
Working temperature: 10–30°C
Refrigerant: R134a
Product size: 400 × 432 × 773 mm
The larger storage compartment helps maintain a more convenient supply during busy periods, while the front control panel makes operation straightforward.
BD-88 Compact Ice-Freezing Cabinet
Practical Frozen Space in a Space-Saving Design
The BD-88 provides 88 liters of frozen storage and is designed to maintain temperatures of -18°C or below.
It can be used as part of an ice-making setup for freezing trays, storing prepared ice or preserving other frozen products.
Main specifications
Capacity: 88L
Input voltage: 12V/24V/220V
Temperature: ≤ -18°C
Product size: 550 × 580 × 845 mm
Carton size: 570 × 600 × 885 mm
Net/Gross weight: 31/34 kg
Refrigerant: R134a/R600a
Loading quantity: 236 units per 40HQ
Its upright cabinet format uses floor space efficiently and is suitable for small shops, cafés, rural businesses and supporting ice-storage applications.
BD-198 Solar Ice-Freezing Series
198L Upright Capacity for Larger Ice Storage Requirements
The BD-198 series includes the BD-198-7, BD-198-10 and BD-198-11 configurations.
Each model provides 198 liters of freezing capacity and can maintain temperatures of -18°C or below. The upright design provides organized vertical storage and allows multiple trays or frozen products to be arranged efficiently.
Shared specifications
Capacity: 198L
Input voltage: 12V/24V/220V
Temperature: ≤ -18°C
Product size: 550 × 635 × 1410 mm
Carton size: 570 × 650 × 1455 mm
Net/Gross weight: 49/52 kg
Refrigerant: R134a/R600a
Loading quantity: 123 units per 40HQ
The BD-198 series is suitable for businesses that need more frozen space but prefer a narrow upright cabinet rather than a wide chest freezer.
One Product Range, Multiple Ice-Making Needs
The four product groups serve different levels of demand:
| Model | Main Function | Capacity or Output | Best Suited For |
|---|---|---|---|
| IM-10 | Compact automatic ice making | 10 kg/day | Home, office, small shops, mobile use |
| IM-30B | Commercial automatic ice making | 30 kg/day | Restaurants, cafés, hotels, retail |
| BD-88 | Ice freezing and frozen storage | 88L | Small shops and supporting ice storage |
| BD-198 Series | Larger upright ice freezing and storage | 198L | Commercial use and larger projects |
Users can select a compact ice maker for direct automatic ice production, or combine an ice maker with a freezing cabinet when additional frozen storage is required.
Suitable for Diverse Applications
Beverage and Food Retail
Ice makers can support cold-drink preparation in cafés, restaurants, grocery stores and beverage kiosks.
Farms and Fisheries
Ice can help cool fresh agricultural products, fish and seafood during temporary handling or local distribution.
Rural and Remote Communities
Solar-compatible equipment offers more flexibility in areas where mains electricity is unavailable or unreliable.
Hotels and Outdoor Businesses
Compact and commercial ice makers can support guest services, outdoor dining and temporary event operations.
Mobile and Small-Scale Businesses
The IM-10 is especially suitable for applications where space and power consumption must be carefully controlled.
Flexible Power for Different Markets
The availability of 12V, 24V and 220V power options allows these products to be configured for different countries and operating environments.
Depending on the project, the equipment may be used with:
Solar panels
Battery storage
Mains electricity
Hybrid solar and mains systems
This flexibility helps distributors, project developers and end users select a system based on local energy conditions.
Supporting More Accessible and Sustainable Ice Production
Solar ice-making equipment is not only about reducing electricity costs. In many regions, it can make ice production possible where conventional refrigeration infrastructure is limited.
A reliable local ice supply can support:
Food and beverage businesses
Seafood handling
Rural retail
Hospitality
Outdoor commerce
Community services
By combining efficient ice production, frozen storage and flexible DC power options, this product range provides practical solutions for a wider variety of users and markets.
Clean Energy, Reliable Ice, More Business Possibilities
From the compact IM-10 to the larger IM-30B and BD-series freezing cabinets, our solar ice-making range is designed to meet different requirements for output, storage, installation space and energy supply.
As solar technology becomes more widely adopted, these products can help businesses and communities gain access to dependable ice production with greater energy flexibility.
